7-10 MFP Service Manual
7510
Assembly 8: Media feed unit
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1 40X3679 4 1 Media feed unit assembly
2 40X3687 4 1 Media out actuator
3 40X3688 30 1 Sensor (tray media out)
4 40X3688 30 1 Sensor (tray media level)
5 40X3684 4 1 Media feed lift motor
6 40X0888 6 1 Bushing 6 mm
7 40X0590 2 1 Pick roll assembly spring
8 40X3686 4 1 Media tray lift one-way gear
9 40X3685 4 1 Media tray lift one-way clutch
10 40X4086 4 2 Separation roll friction clutch
11 40X0594 2 1 Feed unit roll kit
• Feed roll (2)
• Pick roll (2)
• Separation roll (2)
12 40X3690 4 1 Feed roll one-way clutch
13 40X3691 4 1 Feed roll one-way gear 22T
14 40X0952 6 1 Bushing 6 mm
