Parts catalog 7-41
7510
Assembly 35: ADF base
Asm
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X2257 1 1 ADF left hinge
2 40X3883 1 1 ADF registration pinch/frame assembly (this comes assembled)
3 40X2247 7 1 Large hook/loop strip
4 40X2330 5 1 Spring
5 40X2354 1 1 Registration pad
6 40X4104 1 1 Registration pad cover
7 40X2248 1 1 Solenoid/interlock cable assembly
8 40X5978 1 1 ADF controller card assembly
9 40X2259 1 1 ADF interface cable assembly
10 40X2258 1 1 ADF right hinge
