Parts catalog 7-43
7510
Assembly 36: ADF feeder
Asm
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X3884 1 1 ADF left cover assembly (this comes assembled)
2 40X2265 1 1 Registration motor cable assembly
3 40X2266 1 1 ADF feed motor cable assembly
4 40X2264 1 1 Document set/sheet through cable assembly
5 40X2267 1 1 Left cover hinge retainer
6 40X2270 1 1 Registration main drive belt
7 40X2269 1 1 Stud screw
8 40X2327 1 1 ADF feed motor assembly (this comes assembled)
9 40X2383 1 1 ADF main feed assembly (this comes assembled)
10 40X2272 1 1 Document set LED
11 40X2256 1 1 Inverter lever
12 40X2271 1 1 Inverter solenoid assembly
13 40X2273 1 1 Separation roll guide assembly (this comes assembled)
