Parts catalog 7-47
7510
Assembly 38: ADF media guide
Asm
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X3890 1 1 Actuator/media guide assembly (this comes assembled)
2 40X2289 1 1 Inverter gate
3 40X2288 1 1 ADF main feed cable assembly
4 40X2223 1 1 Sensor (ADF pre-registration)
5 40X0589 1 1 Sensor (ADF registration)
6 40X2223 13 1 Sensor (ADF width APS 1)
7 40X2223 13 1 Sensor (ADF width APS 2)
8 40X2223 13 1 Sensor (ADF width APS 3)
9 40X2223 13 1 Sensor (ADF inverter)
10 40X3889 2 1 Media scan guide spring
11 40X3888 1 1 Media scan guide
12 40X2286 1 1 Switch (ADF left cover interlock)
