7-54 MFP Service Manual

7510

Go Back

Assembly 43: CCD lens assembly

Asm

Index

Part

number

Units/

mach

Units/ kit

or pkg

Description

1 40X3867 1 1 Scanner main cable assembly

2 40X3864 1 1 Scanner LVPS cable assembly 110 V

2 40X4037 1 1 Scanner LVPS cable assembly 220 V

3 40X3865 1 1 Scanner LVPS card assembly 110 V

3 40X3866 1 1 Scanner LVPS card assembly 220 V

4 40X3862 1 1 Scanner LVPS cooling fan assembly

5 40X2224 1 1 ADF angle actuator assembly

6 40X2223 2 1 Sensor (ADF angle)

7 40X3861 1 1 CCD card/lens assembly

8 40X4036 1 1 CCD ribbon cable assembly

9 40X2320 2 1 Sensor (platen length APS 1)

10 40X2320 2 1 Sensor (platen length APS 2)

11 40X2222 1 1 Switch (platen interlock)
