Parts catalog 7-77
7510
Assembly 57: 3TM left door
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1 40X3818 1 1 Tray 2 feed-out sensor cable assembly
2 40X3817 1 1 Sensor (tray 2 feed-out)
3 40X3821 1 1 Switch (tray module left door interlock)
4 40X3819 1 1 Tray 3/4 feed-out sensor actuator
5 40X3820 2 1 Sensor (tray 3 feed-out)
6 40X3820 2 1 Sensor (tray 4 feed-out)
7 40X3816 1 1 3TM left door assembly (this comes assembled)
8 40X4035 2 1 Tray 3/4 feed-out sensor cable assembly
9 40X4119 3 1 Tray module media transport roll assembly
