Assembly 60: TTM media trays

Asm-

index

Part

number

FRUs/

mach

Units/

FRU

Description

1 40X3678 3 6 Media tray assembly kit

• Media tray assembly

• #1 label

• #2 label

• #3 label

• #4 label

• Instruction label

2 40X3830 2 1 Switch (TTM media size)

3 40X3831 4 1 TTM tray support roll

4 40X3829 1 3 TTM media tray 4 assembly kit

• TTM media tray 4

• #4 label

• Instruction label

5 40X3828 1 2 TTM media tray 3 assembly kit

• TTM media tray 3

• #3 label

• Instruction label

6 40X3677 3 1 Switch (media size)

7 40X3675 3 1 Media tray catch

8 40X3676 2 1 Media tray slide
