7-84 MFP Service Manual
7510
Go Back
Previous
Next
Assembly 61: TTM tray 3
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1 40X0711 2 1 TTM tray separation pad
2 40X3832 1 1 TTM tray 3 front cover
3 40X4126 4 1 TTM tray lift idler pulley
4 40X4127 4 1 TTM tray lift idler pulley guide
5 40X4084 4 1 TTM tray 3 lift cable
6 40X0708 2 1 TTM large idler pulley kit
• TTM large idler pulley
• TTM large idler pulley guide
7 40X3834 2 1 TTM tray 3 slide strip
8 40X3835 2 1 TTM tray 3 slide button
