Parts catalog 7-91
7510
Assembly 67: TTM drive and electrical
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1 40X3850 1 1 TTM controller card assembly
2 40X3849 1 1 TTM tray 4 transport drive motor assembly
3 40X3812 2 1 Tray module drive motor assembly
4 40X4068 1 1 Tray module left retaining bracket
5 40X3815 1 3 Media transport gear 33T
6 40X3813 1 1 Media transport gear 23/46T
7 40X3814 1 2 Media transport gear 46T
8 40X4034 1 1 Tray module retainer screw
9 40X4117 2 1 Front locking caster
10 40X4143 2 1 Rear non-locking caster
11 40X4069 1 1 Tray module right retaining bracket
12 40X4103 1 1 TTM main cable assembly
