NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 84 Tie Line Delay Ring Pattern Selection
A6-324000-642-02 - Release 6.0 May 2003
The Ring Patterns are shown in the table below:
s= seconds
Pattern
A
B
C
D
E
F
G
H
NIL No Ring
0s 1s 2s 3s 4s 5s 6s
