NEC Xen Master - 3-27 Tie Line Dial Tone Selection

1 - 286 Tie Line Dial Tone Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
3-27
System Mode
3
Submode
—
Data No.
27
PC Programming
a
+ALT
Tie Line Dial Tone Selection
General Description
Use this Memory Block to specify whether or not to send a dial tone to the distant system.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
No Yes
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + BG to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
S to go to the next page
T to go to the previous page
R to go to the next CO/PBX Line No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-14
Tie/DID Line Type Assignment
0 1 / 2 7 : S D T Y S
T I M E D I S P L A Y
CO/PBX
No.
(01~64)
Data
No.
Title
Setting
Data
