NEC Xen Master - 1-8-35 COM Port Baud Rate Setting Assignment

1 - 222 COM Port Baud Rate Setting Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
1-8-35
System Mode
1
Submode
8
Data No.
35
PC Programming
a
+CSS
COM Port Baud Rate Setting
Assignment
General Description
Use this Memory Block to define the baud rates for all three COM ports individually.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
4.8 9.6 19.2 38.4
Programming Procedures
1 Go off-line.
2 Press LK1 + LK8 +
CE to access the Memory Block.
3 Use the Line keys to select the baud rate for each COM port. Default Values
COM 1 = 38.4
COM 2 = 4.8
COM 3 = 4.8 (Not Used)
COM 4 = 9.6
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-5-13
Printer Connected Selection
N
COM 1 = PC Programming/LCR
COM 2 = Station Message Detail Recording (SMDR)
COM 3 = Not Used
COM 4 = Automatic Call Distribution (Not used by Xen Axis system)
3 5 : B D R T 1 = 3 8 . 4
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
