Multiline Terminal Type Selection 1 - 369
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
4-50
System Mode
4
Submode
—
Data No.
50
PC Programming
a
+BTM
Multiline Terminal Type Selection
General Description
This Memory Block is used to assign a DTU-32-1(BK)/(WH), or DTU-32D-1/2 (BK)/(WH)
TEL with 16 line keys or 24 line keys.
Display
Settings
LK 1LK 2LK 3LK 4
The shaded area indicates the default setting.
16 24
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK4 +
EK to access the Memory Block.
3 Use line keys to assign 16 or 24 line keys. Default Values
All stations have 16 line keys.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
0 1 / 5 0 : M L T T P 1 6
T I M E D I S P L A Y
Data
No.
Tel Port No.
(01~99)
A0~C0
Title
Setting
Data
N
Telephone ports A0~C0 are ports 100~120.
Line Key Orientation
16 Line Key Type 24 Line Key Type
LK1 LK2 LK3 LK4 DSS 1 DSS 9 LK1 LK2 LK3 LK4
LK17 LK21
LK5 LK6 LK7 LK8 DSS 2 DSS 10 LK5 LK6 LK7 LK8
LK18 LK22
LK9 LK10 LK11 LK12 DSS 3 DSS 11 LK9 LK10 LK11
LK12 LK19 LK23
LK13 LK14 LK15 LK16 DSS 4 DSS 12 LK13 LK14 LK15 LK16
LK20 LK24
DSS 5 DSS 13 DSS 1 DSS 5
DSS 6 DSS 14 DSS 2 DSS 6
DSS 7 DSS 15 DSS 3 DSS 7
DSS 8 DSS 16 DSS 4 DSS 8
