NEC Xen Master Programming Manual

1 - 278 Tie Line/CO/PBX Incoming Signal Detect Time Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
3-19
System Mode
3
Submode
—
Data No.
19
PC Programming
a
+BCT
Tie Line/CO/PBX Incoming Signal
Detect Time Selection
General Description
Use this Memory Block to specify the duration between the time when the incoming signal
from another system is detected and the time when the acknowledgment signal is sent out.
Display
Settings
In Wink Start Method (Page 1)
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
0 ms. (00) 130 ms. (01) 260 ms. (02) 390 ms. (03)
LK 5 LK 6 LK 7 LK 8
520 ms. (04) 650 ms. (05) 780 ms. (06) 910 ms. (07)
(Page 2)
LK 1 LK 2 LK 3 LK 4
1040 ms. (08) 1170 ms. (09) 1300 ms. (10) 1430 ms. (11)
LK 5 LK 6 LK 7 LK 8
1560 ms. (12) 1690 ms. (13) 1820 ms. (14) 1950 ms. (15)
In Delay Method (Page 1)
LK 1 LK 2 LK 3 LK 4
0 ms. (00) 30 ms. (01) 60 ms. (02) 90 ms. (03)
LK 5 LK 6 LK 7 LK 8
120 ms. (04) 150 ms. (05) 180 ms. (06) 210 ms. (07)
(Page 2)
LK 1 LK 2 LK 3 LK 4
240 ms. (08) 270 ms. (09) 300 ms. (10) 330 ms. (11)
LK 5 LK 6 LK 7 LK 8
360 ms. (12) 390 ms. (13) 420 ms. (14) 450 ms. (15)
In COI (Page 1)
LK 1 LK 2 LK 3
LK 4
50 ms. (00) 100 ms. (01) 150 ms (02)
200 ms. (03)
LK 5 LK 6 LK 7 LK 8
250 ms. (04) 300 ms. (05) 350 ms. (06) 400 ms. (07)
(Page 2)
LK 1 LK 2 LK 3 LK 4
450 ms. (08) 500 ms. (09) 550 ms. (10) 600 ms. (11)
LK 5 LK 6 LK 7 LK 8
650 ms. (12) 700 ms. (13) 750 ms. (14) 800 ms. (15)
0 1 / 1 9 : I N C 0 3 | 1
T I M E D I S P L A Y
Data
No.
Title
Page
No.
Setting
Data
