NEC Xen Master - 1-5-13 Printer Connected Selection

1 - 170 Printer Connected Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
1-5-13
System Mode
1
Submode
5
Data No.
13
PC Programming
a
+AS
Printer Connected Selection
General Description
Use this Memory Block to program when a printer or PC is connected for SMDR use. If the
printer is disconnected from the system, an alarm sounds at stations connected to Ports 01
and 02.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
No PC Printer
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK1 + LK5
+ACto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-5-02
SMDR Print Format
1-5-23
Outgoing Mode Selection
1-5-25
SMDR Valid Call Timer Assignment
1-8-35
COM Port Baud Rate Setting Assignment
1-8-36
COM Port Parity/Stop Bit Setting Assignment
N
Station Message Detail Recording (SMDR) cannot be used if this Memory Block is programmed for No.
1 3 : P R I N T E R N O
T I M E D I S P L A Y
Data
No. Title
Setting
Data
