ACR Trunk Group to Route Number Assignment 1 - 249
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
1-14-04
System Mode
1
Submode
14
Data No.
04
PC Programming
a
+AB
ACR Trunk Group to Route
Number Assignment
General Description
Use this Memory Block to specify whether a Trunk Group is used for each Route
assignment.
This feature requires System Software V3.XX or higher.
ICM is allowed as an option with system software version 6.0 or higher.
Display
Settings
LK 1LK 2LK 3LK 4
The shaded selection is the default.
NORMAL
(Originate)
TKGP
(01~32)
ICM
LK 5LK 6LK 7LK 8
Programming Procedures
1 Go off-line.
2 Press LK1 + LK14 +
LDto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the Setting Data 1 option.
Use dial pad keys
K~I to select Data Setting Data 2 Trunk Group Number (01~32) or Setting Data 2 RAB (1~16).
Note: Press
Jto move cursor left.
Press
Lto move cursor right.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-03
Trunk-to-Trunk Group Assignment
4-41
LCR Class Selection
1-8-08
Class of Service (Station) Feature Selection 2
1-14-00
ACR Feature Allow/Deny Selection
1-14-01
ACR Dialling Assignment
1-14-02
ACR Dialled Number Dial Allow/Deny Selection
1-14-03
ACR Route Table Number Assignment
1-14-05
ACR Digit Delete Assignment
1-14-06
ACR Digit Add Assignment
0 4 / 0 1 = N O R M A L
T I M E D I S P L A Y
Data
No.
Setting
Data 1
Route
No.
Setting
Data 2
To Next Page
