1 - 394 OCC Table to Trunk Group Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
5-03
System Mode
5
Submode
—
Data No.
03
PC Programming
a
+AC
The shaded area indicates the default setting.
OCC Table to Trunk Group
Assignment
General Description
Use this Memory Block to assign each of the 16 OCC Tables to each Trunk Group.
Display
Settings
(Page 1)
LK 1 LK 2 LK 3 LK 4
There is no default setting.
Table 00 Table 01 Table 02 Table 03
LK 5 LK 6 LK 7 LK 8
Table 04 Table 05 Table 06 Table 07
(Page 2)
LK 1 LK 2 LK 3 LK 4
Table 08 Table 09 Table 10 Table 11
LK 5 LK 6 LK 7 LK 8
Table 12 Table 13 Table 14 Table 15
Programming Procedures
1 Go off-line.
2 Press LK5 +
N+ KC to access the Memory Block.
3 Press the corresponding CO/PBX line key to enter the data. Operation data includes:
Note: Use the following to enter data:
J to moves the cursor left
L to moves the cursor right
S to go to the next page
T to go to the previous page
R to go to the next Trunk Group No.
Default Values
Use all tables
4 After entering all data for all pages, press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
Refer to Section 6 Code Restriction in this chapter.
0 1 / 0 3 : O C C = T R K G | 1
T I M E D I S P L A Y
Trunk Group No.
(01~32)
Data
No.
Title
Page
No.
CO/PBX
Line LED
Off
On
Data Disabled
Enabled
To Next Page
