1 - 92 8-Digit Matching Table to Class Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
1-1-61
System Mode
1
Submode
1
Data No.
61
PC Programming
a
+AC
8-Digit Matching Table to Class
Assignment
General Description
Use this Memory Block to program, per Class, each 8-digit Matching Table to allow or deny.
Classes 00 and 15 are fixed. Only classes 01
~14 can be programmed.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
NON Allow (YS) Deny (NO)
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK1 + LK1 +
FA to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Class 00 and 15 cannot be programmed.
Class 00 has no restrictions (Allow)
Class 15 has restricted outgoing (Deny)
Refer to the table on the next page.
4 Press
Nto write the data and advance to the next table. Repeat Steps 3 and 4 for each table.
5 After data for the last table is entered, press
Nto write the data.
6 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
Refer to Section 6 Code Restriction in this chapter.
6 1 : C L S 0 1 ( 0 0 ) = Y S
T I M E D I S P L A Y
Data
No.
Title
1~7
Class
No.
01~14
Table
00~15
Setting
Data
To Next Page
