NEC Xen Master Programming Manual

Trunk DTMF Duration/Interdigit Selection 1 - 273
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
3-15
System Mode
3
Submode
—
Data No.
15
PC Programming
a
+BCT
Trunk DTMF Duration/Interdigit
Selection
General Description
Use this Memory Block to specify the tone duration and interdigit time of dual-tone multi-
frequency (DTMF) signals.
Display
Settings
LK 1 LK 2LK 3LK 4
The shaded area indicates the default setting.
D.D. I.T.
60 ms. 70 ms.
D.D. I.T.
60 ms. 80 ms
D.D. I.T.
110 ms 80 ms
D.D. I.T.
160 ms. 80 ms
LK 5 LK 6 LK 7 LK 8
D.D. I.T.
210 ms 80 ms
D.D. I.T.
410 ms 100 ms
D.D. I.T.
610 ms 100 ms
D.D. I.T.
810 ms 190 ms
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + AEto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
R = Next CO/PBX Line No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-91
Trunk (Installed, DP/DTMF) Selection
N
1. This is also used for Tie lines.
0 1 / 1 5 : M F 6 0 / 8 0
T I M E D I S P L A Y
CO/PBX
No.
(01~64)
Data
No.
Title
Setting Data
