NEC Xen Master Programming Manual

May 2003
Programming Manual 1 - 469
A6-324000-642-02 – Release 6.0 May 2003
The diagram shows the Memory Blocks programmed for Digit Insertion.
Digit Insertion
Menu Access
Keyboard Shortcut
System Data Name Memory Block
¦
+BA
Access Code (1~3-Digit) Assignment
1-1-46~48
¦
+BCS
 Networking Trunk Group/Route Advance Assignment
1-1-49
¦
+BCS
 CO/PBX Outgoing Digit Add Assignment
1-1-50
¦
+BCT
Trunk-to-Trunk Group Assignment 3-03
¦
+BS
Station Number Assignment 4-10
Digital Voice Mail
Menu Access
Keyboard Shortcut
System Data Name Memory Block
¦
+BTD
Attendant Add-On Console Key Selection 1-6-05
¦
+BTS
Class of Service (Station) Feature Selection 2
1-8-08
(Pg.4, LK5 & LK6)
¦
+BN
Line Key Selection for Tenant Mode 2-06
¦
+BCT
DIT Assignment 3-42
¦
+BCT
ANA Assignment 3-43
¦
+AV
Live Recording Trunk Selection 3-45
Centrex
Central Office
4600~4620 4621~4899
Xen Master
Other
Centrex
Number
100 ~ 120
Abbreviations:
AC = Access Code
BLK = Block
MB = Memory Block
Calling
Outside Call – Dial 0 (System adds ‘0’)
Centrex Call – 46XX ~ 48XX
Outside Numbers
MB 1-1-46
AC 9 = Item 401
MB 1-1-47
AC 46 = Item 402
AC 47 = Item 403
AC 48 = Item 404
MB 1-1-49
BLK 01= 101
BLK 02= 101
BLK 03= 101
BLK 04= 101
MB 1-1-50
BLK 01= Add 9
BLK 02= Add 46
BLK 03= Add 47
BLK 04= Add 48
