1 - 334 Line Key Selection for Telephone Mode
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
4-12
System Mode
4
Submode
—
Data No.
12
PC Programming
a
+BTM
Line Key Selection for
Telephone Mode
General Description
Use this Memory Block to assign functions to each CO/PBX line key on each telephone in a
tenant specified as Telephone Mode in Memory Block 2-05 Line Key Selection.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
Not Specified CO/PBX Line CFW-B/NA CFW-ALL
LK 5 LK 6 LK 7 LK 8
Call
Appearance
Feature
Access
Trunk Group
Route
Advance
LK 9 LK 10 LK 11 LK 12
SIE/CAR
Microphone
Key
Headset
Scroll Key for
Caller ID
LK 13 LK 14 LK 15 LK 16
DND
On/Off
LOG
On/Off
BGM
On/Off
ICM
Programming Procedures
1 Go off-line.
2 Press LK4 +
ABto access the Memory Block.
3 Press corresponding CO/PBX line key to change setting data 1.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K ~ I to enter setting data 2
Rto move to the next Tel Port No
For example, to assign Trunk Group 5 to CO/PBX line key 1, press LK7 to display
TKGP, and enter 05 (for RT 05) using the dial pad.
Default Values
For Tel 01~CO: LK01~08 Assigned to
CO/PBX lines 01~08.
4 Press
Nto write the data and display the next line key.
5 Repeat example and step 4 until all line key assignments are complete, and press
Nto enter last data.
6 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
2-06
Line Key Selection for Tenant Mode
0 1 / 1 2 : L 0 1 = C O 0 1
T I M E D I S P L A Y
Data
No.
Tel Port
No.
(01~99)
A0~C0
Setting
Data 2
Setting
Data 1
Line Key No.
(01~24)
To Next Page
