NEC Xen Master Programming Manual

1 - 186 Doorphone Ringing Frequency Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
1-7-05
System Mode
1
Submode
7
Data No.
05
PC Programming
a
+BTP
Doorphone Ringing Frequency
Selection
General Description
Use this Memory Block to define the doorphone ringing frequency. Each doorphone can be
individually assigned.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
Freq A Freq B Freq C Freq D
LK 5 LK 6 LK 7 LK 8
Freq E Freq F Freq G Freq H
Programming Procedures
1 Go off-line.
2 Press LK1 + LK7
+KEto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-7-00
Doorphone Assignment
1-7-04
Doorphone Ringing Pattern Selection
0 5 : D P H F R E Q C
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
