1 - 100 8-Digit Matching Table to OCC Table Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
1-1-68
System Mode
1
Submode
1
Data No.
68
PC Programming
a
+AC
8-Digit Matching Table to OCC
Table Assignment
General Description
Use this Memory Block to assign each 8-Digit Matching Table to each Other Common
Carrier (OCC) Code Table.
Display
Settings
(Page 1)
LK 1 LK 2 LK 3 LK 4
There is no default setting.
Table 00 Table 01 Table 02 Table 03
LK 5 LK 6 LK 7 LK 8
Table 04 Table 05 Table 06 Table 07
(Page 2)
LK 1 LK 2 LK 3 LK 4
Table 08 Table 09 Table 10 Table11
LK 5 LK 6 LK 7 LK 8
Table 12 Table13 Table14 Table15
Programming Procedures
1 Go off-line.
2 Press LK1 +
LK1 + FH to access the Memory Block.
3 Press the corresponding CO/PBX line key to change data option.
Note: Use the following to enter data:
Sto access the next page
Tto access the previous page.
Each time a CO/PBX line key is pressed, the LED toggles between On
and Off.
Default Values
OCC Tables 01~15:
All Matching Tables Not Used
OCC Table 16:
Matching Tables 00~14 Not Used
Matching Table 15 Used
4 Press
Nto write the data and advance to the next OCC table. Repeat steps 3 and 4 until last OCC data is assigned.
5 Press
Nto write the last data.
6 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
Refer to Section 6 Code Restriction in this chapter.
6 8 : 8 D G O C C ( 0 1 ) | 1
T I M E D I S P L A Y
Data
No.
Table
01~16
Title
Function No.
CO/PBX
Line LED
Off On
Data Unused Used
There is no default setting.
To Next Page
