1 - 248 ACR Route Table Number Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
1-14-03
System Mode
1
Submode
14
Data No.
03
PC Programming
a
+AO
ACR Route Table Number
Assignment
General Description
Use this Memory Block to assign each ACR Dialing Assignment to an ACR Route
Assignment.
This feature requires System Software S3.XX or higher.
Display
Programming Procedures
1 Go off-line.
2 Press LK1 + LK14 +
LCto access the Memory Block.
3 Use dial pad keys to select Table number (1~4), Dial number (01~C8), and Route number (01~32).
Use dial pad keys
K~I to select Data
Note: Use
Jto move cursor left.
Use
Lto move cursor right.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-03
Trunk-to-Trunk Group Assignment
4-41
LCR Class Selection
1-8-08
Class of Service (Station) Feature Selection 2
1-14-00
ACR Feature Allow/Deny Selection
1-14-01
ACR Dialling Assignment
1-14-01
ACR Dialled Number Dial Allow/Deny Selection
1-14-03
ACR Trunk Group to Route Number Assignment
1-14-05
ACR Digit Add Assignment
1-14-04
ACR Digit Delete Assignment
N
1. Entries A0~C8 are 100~128.
2. If ACR Route Assignment 00 is selected, the call is sent to Trunk Group 01 exactly as it was dialed.
0 3 : 1 / 0 1 R O U T E 0 0
T I M E D I S P L A Y
Data
No.
Setting
Data
01~C8
Dial
No.
Title
Table
1~4
To Next Page
