LCR Class Selection 1 - 361
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
4-40
System Mode
4
Submode
—
Data No.
40
PC Programming
a
+BTT
LCR Class Selection
General Description
Use this Memory Block to specify, per station, the Least Cost Routing (LCR) Class. The
Xen Master/Axis system has four Area Code Tables. Each LCR Class can have different
Trunk Group access to allow priority levels for the station user.
Display
Settings
LK 1LK 2LK 3LK 4
The shaded area indicates the default setting.
Class 0 Class 1 Class 2 Class 3
LK 5 LK 6 LK 7 LK 8
Class 4
Programming Procedures
1 Go off-line.
2 Press LK4 +
DK to access the Memory Block.
3 Press the corresponding CO/PBX line key to change data option.
Note: Use the following to change option:
Rto select next Tel Port No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
N
1. LCR Class Selection corresponds to Area Code Tables as follows:
Class 0 No LCR
Class 1 Use Area Code Table 1
Class 2 Use Area Code Table 2
Class 3 Use Area Code Table 3
Class 3 Use Area Code Table 3
2. Stations cannot be assigned to multiple LCR Classes.
3. An MIFM PAL must be installed in the system to support this feature.
4. Telephone ports A0~C0 are ports 100~120.
5. Access Code must always be used in order to access LCR Trunk Group 1.
0 1 / 4 0 : L C R C L S = 0
T I M E D I S P L A Y
Data
No.
Tel Port No.
(01~99)
A0~C0
Title
Setting
Data
To Next Page
