NEC Xen Master Programming Manual

Trunk to Tenant Assignment 1 - 253
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
2-01
System Mode
2
Submode
—
Data No.
01
PC Programming
a
+BN
Trunk to Tenant Assignment
General Description
Use this Memory Block to assign CO/PBX lines to a tenant.
Display
Settings
(Page 1) (Page 5)
LK 1 LK 2 LK 3 LK 4 LK 1 LK 2 LK 3 LK 4
01 02 03 04 33 34 35 36
LK 5 LK 6 LK 7 LK 8 LK 5 LK 6 LK 7 LK 8
05 06 07 08 37 38 39 40
(Page 2) (Page 6)
LK 1 LK 2 LK 3 LK 4 LK 1 LK 2 LK 3 LK 4
09 10 11 12 41 42 43 44
LK 5 LK 6 LK 7 LK 8 LK 5 LK 6 LK 7 LK 8
13 14 15 16 45 46 47 48
(Page 3) (Page 7)
LK 1 LK 2 LK 3 LK 4 LK 1 LK 2 LK 3 LK 4
17 18 19 20 49 50 51 52
LK 5 LK 6 LK 7 LK 8 LK 5 LK 6 LK 7 LK 8
21 22 23 24 53 54 55 56
(Page 4) (Page 8)
LK 1 LK 2 LK 3 LK 4 LK 1 LK 2 LK 3 LK 4
25 26 27 28 57 58 59 60
LK 5 LK 6 LK 7 LK 8 LK 5 LK 6 LK 7 LK 8
29 30 31 32 61 62 63 64
Note: All line keys are a default setting.
0 0 / 0 1 : T R K - T N T | 0 1
T I M E D I S P L A Y
Data
No.
Title
Tenant
No.
(00~47)
Trunk
