NEC Xen Master - 4-95 DTMF;DP SLT Type Selection

1 - 388 DTMF/DP SLT Type Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
4-95
System Mode
4
Submode
—
Data No.
95
PC Programming
a
+BTI
DTMF/DP SLT Type Selection
General Description
Use this Memory Block to specify, per port, whether Dial Pulse or Dual-Tone Multifrequency
Single Line Telephone is connected to the system.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
DP DTMF (MF)
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK4 +
IE to access the Memory Block.
3 Press the corresponding CO/PBX line key to change data option.
Note: Use the following to change option:
Rto select next Tel Port No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
N
1. The DP selection supports 10 pps or 20 pps.
2. Telephone ports A0~C0 are ports 100~120.
0 1 / 9 5 : S L T = M F
T I M E D I S P L A Y
Data
No.
Tel Port No.
(01~99)
A0~C0
Title
Setting
Data
