1 - 326 Doorphone Chime Assignment (Night Mode)
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
4-04
System Mode
4
Submode
—
Data No.
04
PC Programming
a
+BTP
Doorphone Chime Assignment
(Night Mode)
General Description
Use this Memory Block to assign up to four doorphones to ring at each station in the
Night Mode.
Display
Settings
Page 1 (Ports 01~08)
LK 1 LK 2 LK 3 LK 4
There is no default setting.
DP1 DP2 DP3 DP4
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK4 +
KD to access the Memory Block.
3 Use LK1~LK4 to assign doorphone ringing for each station. Default Values
Ports 01 and 02 ring for all doorphones.
4 After entering all data, press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-7-00
Doorphone Assignment
1-7-01
Doorphone Display Time Selection
1-7-04
Doorphone Ringing Pattern Selection
1-7-05
Doorphone Ringing Frequency Selection
N
Telephone ports A0~C0 are ports 100~120.
0 1 / 0 4 : D P H N I G H T
T I M E D I S P L A Y
Data
No.
Title
Tel Port
No.
(01~99)
A0~C0
To Next Page
