NEC Xen Master Programming Manual

Doorphone Ringing Pattern Selection 1 - 185
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
1-7-04
System Mode
1
Submode
7
Data No.
04
PC Programming
a
+BTP
Doorphone Ringing Pattern
Selection
General Description
Use this Memory Block to define the doorphone ringing cycle. Each doorphone can be
individually assigned.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
Off On Cycle A Cycle B
LK 5 LK 6 LK 7 LK 8
Cycle C Cycle D Cycle E Cycle F
LK 1LK 2LK 3LK 4
Cycle G Cycle H
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK1 + LK7
+KDto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option. Default Values
All doorphones are LK2
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-7-00
Doorphone Assignment
1-7-05
Doorphone Ringing Frequency Selection
0 4 : D P H C Y C L O N
|
1
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
