NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 4 Multiline Terminal Programming
A6-324000-642-02 - Release 6.0
May 2003
2.4 Writing System Data
After turning on the system, system data can be programmed using a Multiline
Terminal that is connected to ports 01 or 02 (the Multiline Terminal must be idle).
System programming can be performed while other Multiline Terminals in the
system are in use. Some data is written into memory immediately after the
programming process, while other data is not written until the stations or trunks are
idle. When the data is not written until a station or trunk is idle, the station LCD
displays ‘DATA ENTRY’ even after the programming process is completed. This
indicates that system data entry is still in progress. When the in-use stations
become idle, the data is written and the station LCD displays only the time.
The data programmed for the following Memory Blocks is not written while the
Multiline Terminals or PBRs are in use:
 When Multiline Terminals are in use:
• Memory Block 2-01 (Trunk to Tenant Assignment)
• Memory Block 2-05 (Line Key Selection)
• Memory Block 2-07 (System Speed Dial Display Assignment)
• Memory Block 4-09 (Telephone to Tenant Assignment)
 When the PBR is in use:
• Memory Block 1-8-01 (SLT or Automated Attendant/DISA to PBR
Selection)
• Memory Block 1-8-02 (PBR Receive Level Assignment for Automated
Attendant/DISA)
