Code Restriction Class Allow/Deny Selection 1 - 97
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
1-1-65
System Mode
1
Submode
1
Data No.
65
PC Programming
a
+AC
Code Restriction Class Allow/Deny
Selection
General Description
Use this Memory Block to assign Code Restriction Classes 01~14 as Allow or Deny. This
assignment is used when there is no match or there is an overlap (duplicate numbers in
tables with opposite assignments) of numbers in the 8-Digit Matching Tables.
Display
Settings
LK 1LK 2LK 3LK 4
The shaded area indicates the default setting.
Allow (YS) Deny (NO)
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK1 +
LK1 + FE to access the Memory Block.
3 Press the corresponding CO/PBX line key to change data option. Default Values
Class 01 Deny (NO)
Class 02~14 Allow (YES)
4 Press
Nto write the data and advance to the next class. Repeat steps 3 and 4 until last class is assigned.
5 Press
Nto write selected data.
6 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
Refer to Section 6 Code Restriction in this chapter.
N
1. If a match is not found or duplicate match is made with opposite assignments, the system uses this Memory Block.
2. If the interdigit dialling time duration exceeds 10 seconds while a restricted station user is dialling on an outside line,
the system automatically drops the call.
3. If phones are required to dial emergency “only”, then class 01 can be used.
4. Use Memory Block 1-1-70 as the default class assignment for features such as station outgoing lockout In/Out (from
DSS console and password lockout.
6 5 : C L A S S ( 0 1 ) = Y S
T I M E D I S P L A Y
Data
No.
Class
No.
01~14
Title
Function
To Next Page
