Example:
The diagram provides an example of Memory Blocks that would be programmed for a Closed Numbering Plan.
Abbreviations used in the diagram
:
AC = Access Codes BLK = Block MB = Memory Block TRK = Trunk
ACG = Access Item Code LN = Line TG = Trunk Group UD = Uniform Dial
Xen
System
(100’s)
Xen
System
(200’s)
Xen
System
(300’s)
Tie Lines
(LN 09) – (LN 09)
(LN 10) – (LN 10)
(TG 02) (TG 02)
Tie Lines
(LN 11) – (LN 09)
(LN 12) – (LN 10)
(TG 03) (TG 02)
100 ~ 130 200 ~ 230 300 ~ 330
Calling
200 ~ 230
300 ~ 330
400 ~ 430
MB 1-1-46
AC 2 = Item 401
AC 3 = Item 402
AC 4 = Item 403
MB 1-1-49
BLK 01 = 102
BLK 02 = 102
BLK 03 = 102
MB 1-1-50
BLK 01 = Add 2
BLK 02 = Add 3
BLK 03 = Add 4
MB 3-03
TRK 09 = TG 02
TRK 10 = TG 02
MB 5-01
Default OK
Calling
100 ~ 130
300 ~ 330
400 ~ 430
MB 1-1-46
AC 1 = Item 401
AC 2 = Item 001
AC 3 = Item 402
AC 4 = Item 403
MB 1-1-49
BLK 01 = 102
BLK 02 = 103
BLK 03 = 103
MB 1-1-50
BLK 01 = Add 1
BLK 02 = Add 3
BLK 03 = Add 4
MB 3-03
TRK 09 = TG 02
TRK 10 = TG 02
TRK 11 = TG 03
TRK 12 = TG 03
MB 4-10
All Phones = 2XX
MB 5-01
Default OK
Calling
100 ~ 130
200 ~ 230
400 ~ 430
MB 1-1-46
AC 1 = Item 401
AC 2 = Item 402
AC 3 = Item 001
AC 4 = Item 403
MB 1-1-49
BLK 01 = 102
BLK 02 = 102
BLK 03 = 103
MB 1-1-50
BLK 01 = Add 1
BLK 02 = Add 3
BLK 03 = Add 4
MB 3-03
TRK 09 = TG 02
TRK 10 = TG 02
TRK 11 = TG 03
TRK 12 = TG 03
MB 4-10
All Phones = 3XX
MB 5-01
Default OK
Uniform Numbering Network – Open Numbering Plan
Menu Access
Keyboard Shortcut
System Data Name Memory Block
¦
+BA
Access Code (1-, 2-, or 3-Digit) Assignment
1-1-46/47/48
¦
+BCS
Networking Trunk Group/Route Advance Assignment
1-1-49
¦
+BCS
CO/PBX Outgoing Digit Add Assignment
1-1-50
¦
+BCT
Trunk-to-Trunk Group Assignment 3-03
¦
+BCT
Trunk (Installed, DP/DTMF) Selection 3-92
