Route Advance Block Assignment 1 - 59
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
1-1-30
System Mode
1
Submode
1
Data No.
30
PC Programming
a
+BCS
Route Advance Block Assignment
General Description
Use this Memory Block to assign priority levels (1~4) to each Trunk Group assigned in a
Route Advance Block. The system has 16 blocks that can be specified. For main software
version 6.0 and above, 32 blocks are allowed.
Display
Programming Procedures
1 Go off-line.
2 Press LK1 +
LK1 + CK to access the Memory Block.
3 Enter the data using the dial pad.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K~I to enter numeric data
32 Blocks are allowed for main software version 6.0 and above.
Default Values
All Blocks (00)
4 Press
Nto write the data. Data for the Priority Nos. 2~4 are displayed in succession.
5 After entering the data for Priority No. 4, press
Nto write the data. Data for Priority 1 for the next Block No. is displayed.
6 After entering data for Block No. 16, press
Nto write the data. The next Memory Block is displayed.
7 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-03
Trunk-to-Trunk Group Assignment
3 0 : R T A D V 0 1 - 1 = 0 0
T I M E D I S P L A Y
Data
No.
Block
No.
(1~16)
Title
Setting
Data
Priority
No.
(1~4)
Block No. Priority No. Setting Data
1
1 Trunk Groups 01~32
2 Trunk Groups 01~32
3 Trunk Groups 01~32
4 Trunk Groups 01~32
16
1 Trunk Groups 01~32
2 Trunk Groups 01~32
3 Trunk Groups 01~32
4 Trunk Groups 01~32
∼
∼
∼
