1 - 276 Tie Line Release Detect Time Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
3-18
System Mode
3
Submode
—
Data No.
18
PC Programming
a
+ALM
Tie Line Release Detect Time
Selection
General Description
Use this Memory Block to specify the duration between the time when the circuit
disconnection is detected on the Tie line on the distant system side and the time when it is
recognized as Tie line release.
Display
Settings
(Page 1)
LK 1 LK 2
LK 3 LK 4
The shaded area indicates the default setting.
0 ms. 130 ms. 260 ms. 390 ms.
LK 5 LK 6 LK 7 LK 8
520 ms. 650 ms. 780 ms. 910 ms.
(Page 2)
LK 1 LK 2 LK 3 LK 4
1040 ms. 1170 ms. 1300 ms. 1430 ms.
LK 5 LK 6 LK 7 LK 8
1560 ms. 1690 ms. 1820 ms. 1950 ms.
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + AH to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: The following are used when entering data:
S to go to the next page
T to go to the previous page
R to go to the next CO/PBX Line No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
0 1 / 1 8 : R L S 2 6 0 | 1
T I M E D I S P L A Y
CO/PBX
No.
(01~64)
Data
No.
Title
Setting
Data
Page
No.
To Next Page
