Page #343 background imageLoading...
Page #343 background image
Doorphone Chime Assignment (Day Mode) 1 - 325
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
4-03
System Mode
4
Submode
—
Data No.
03
PC Programming
a
+BTP
Doorphone Chime Assignment
(Day Mode)
General Description
Use this Memory Block to assign up to four doorphones to ring at each station in the
day mode.
Display
Settings
Page 1 (Ports 01~08)
LK 1LK 2LK 3LK 4
There is no default setting.
DP1 DP2 DP3 DP4
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK4 +
KC to access the Memory Block.
3 Use LK1~LK4 to assign ringing for doorphone 1~4. Default Values
Port 01 and 02 ring for all doorphones.
4 After entering all data, press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-7-00
Doorphone Assignment
1-7-01
Doorphone Display Time Selection
1-7-04
Doorphone Ringing Pattern Selection
1-7-05
Doorphone Ringing Frequency Selection
N
Telephone ports A0~C0 are ports 100~120.
0 1 / 0 3 : D P H D A Y
T I M E D I S P L A Y
Data
No.
Title
Tel Port
No.
(01~99)
A0~C0
