NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 324 CO/PBX Ring Assignment (Night Mode)
A6-324000-642-02 - Release 6.0
May 2003
Page 6 (Ports 41~48)
LK 1LK 2LK 3LK 4
41 42 43 44
LK 5 LK 6 LK 7 LK 8
45 46 47 48
Page 7 (Ports 49~56)
LK 1LK 2LK 3LK 4
49 50 51 52
LK 5 LK 6 LK 7 LK 8
53 54 55 56
Page 8 (Ports57~64)
LK 1LK 2LK 3LK 4
57 58 59 60
LK 5 LK 6 LK 7 LK 8
61 62 63 64
Programming Procedures
1 Go off-line.
2 Press LK4 +
KB to access the Memory Block.
3 Press the CO/PBX Line key corresponding to each CO/PBX number.
The LED indication changes to indicate data each time a CO/PBX line key is
pressed.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
Rto move to the next Tel No.
S to move to the next page
T to move to the previous page
Default Values
Tel Port numbers 01 and 02 ring on
CO/PBX lines 01
~ 08.
Tel Port numbers 03
~ 96 do not ring
on any incoming CO/PBX calls.
4 After entering all data for all pages, Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
N
Telephone ports A0~C0 are ports 100~120.
Settings
CO/PBX
Line Key LED
Off Green Red
Data No ring
Immediate
Ring
Delayed
Ring
There is
no default
setting.
