NEC Xen Master Programming Manual

NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 10 Multiline Terminal Programming
A6-324000-642-02 - Release 6.0 May 2003
SECTION 3
S
YSTEM DATA LIST
The following table provides a complete list of Memory Blocks that are available in
the Xen system. The information is organized by mode, submode, and then
numerically by Memory Block number. The Memory Block number and name, the
default values, and programming values are provided for each Memory Block.
Table 1-3 System Data
LK 1 System Mode
LK 1 CO Line
Data
No.
Memory Block Name Default Value Programming Values
00 Pause Time Selection 3 sec. 1 sec., 3 sec.
01 DP Interdigit Time Selection Pattern B Pattern A
10 pps: 650 ms
20 pps: 500 ms
Pattern B
10 pps: 800 ms
20 pps: 800 ms
02 Hookflash Time Selection 100 ms. 20 ms., 40 ms., 60 ms.,
80 ms., 100 ms., 140 ms.,
160 ms., 200 ms.
400 ms., 600 ms., 800 ms.,
1 sec., 1.5 sec., 2 sec., 3 sec.,
5 sec.
03 Hold Recall Timer Selection (Non-
Exclusive Hold)
60 sec. 25 sec., 45 sec., 60 sec., 90 sec., 120 sec.,
180 sec., 240 sec., No Limit
04 Automatic Redial Time Selection Calling Time = 30 sec
Waiting Time = 60 sec
Call Attempts = 2 times
Calling Time: 1~5 sec
Waiting Time: 1~100 sec
Call Attempts: 1~9 times (3 digit input)
05 Start Timer Selection 10 sec. 2 sec., 10 sec., 20 sec., 30 sec.,
40 sec. , 50 sec., 60 sec., 70 sec.
06 CO/PBX Incoming Ringing Alarm Time
Selection
No Limit 10 sec., 20 sec., 30 sec., No Limit
07 Tie Line Delay Ringing Timer Selection No Limit 10 sec., 20 sec., 30 sec., No Limit
09 Manual Pause Selection No No, Yes
11 System Transfer/Camp-On Selection Yes No, Yes
12 Station Transfer/Camp-On Recall Timer
Selection
60 sec. 25 sec., 45 sec., 60 sec., 90 sec., 120 sec.,
180 sec., 240 sec., No Limit
13 CO Transfer Ring Pattern Selection Pattern C Tone Off, Tone On, Patterns A ~ H
14 CO Transfer Ring Tone Selection Tone A Tones A ~ H
18 System Speed Dial Restriction by
Tenant
Not Restricted LED On: Not Restricted
LED Off: Restricted
19 Line Selection for Automatic Outgoing
Calls
20 DID Digit Length Selection 2 Digits 2, 3, or 4 digits
21 DID Digit Conversion Assignment Yes No, Yes
