1 - 320 Trunk (Installed, DP/DTMF) Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
3-92
System Mode
3
Submode
—
Data No.
92
PC Programming
a
+BCT
Trunk (Installed, DP/DTMF)
Selection
General Description
This Memory Block specifies each external line as DP (10 pps or 20 pps) or DTMF line or
not connected (NIL).
New Zealand - DP is not supported.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
NIL DP 10 pps DP 20 pps MF
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + IB to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
R to go to the next CO/PBX Line No.
4 PressNto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-14
Tie/DID Line Type Assignment
4-12
Line Key Selection for Telephone Mode
N
1. When Port 01 displays CO XX layer message, use NIL setting for unused BRI interfacing to clear display.
0 1 / 9 2 : M F
T I M E D I S P L A Y
Setting
Data
Data
No.
CO/PBX
No.
(01~64)
To Next Page
