NEC Xen Master - 3-14 Tie;DID Line Type Assignment

1 - 272 Tie/DID Line Type Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0 May 2003
3-14
System Mode
3
Submode
—
Data No.
14
PC Programming
a
+ALT
Tie/DID Line Type Assignment
General Description
Use this Memory Block to assign the method of loop supervision to be used for each Trunk
associated with a Tie line.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
2nd Dial
Tone
Immediate Delayed
Wink
Start
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + ADto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
R to go to the next CO/PBX Port No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-91
Trunk (Installed, DP/DTMF) Selection
N
1. Line keys 1~4 correspond to the following methods of loop supervision:
1 = Second Dial Tone
2 = Immediate Start
3 = Delay Dial
4 = Wink Start
2. If a second dial tone is selected, the distant system provides the dial tone.
3. If Immediate, Delay, or Wink Start is selected, the local system provides the dial tone.
0 1 / 1 4 : I M M E D I A T E
T I M E D I S P L A Y
Ti
e
/DID
No.
(01~64)
Data
No.
Title
