CO Ringing Pattern Selection for Telephone Mode 1 - 373
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
4-55
System Mode
4
Submode
—
Data No.
55
PC Programming
a
+BTT
CO Ringing Pattern Selection
for Telephone Mode
General Description
Use this Memory Block to assign the ring pattern of telephones for CO/PBX calls.
Display
Settings
Page 1
LK 1LK 2LK 3LK 4
The shaded area indicates the default setting.
—A B C
LK 5 LK 6 LK 7 LK 8
DEFG
Page 2
LK 9 LK 10 LK 11 LK 12
H
LK 13 LK 14 LK 15 LK 16
Programming Procedures
1 Go off-line.
2 Press LK4 +
EEto access the Memory Block.
3 Press corresponding CO/PBX line key to change setting data 1.
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K ~ I to enter setting data 2
Rto move to the next Tel Port No
For example, to assign Trunk Group 5 to CO/PBX line key 1, press LK7 to display
TKGP, and enter 05 (for RT 05) using the dial pad.
Default Values
:
— = NONE
4 Press
Nto write the data and display the next line key.
5 Repeat example and step 4 until all line key assignments are complete, and press
Nto enter last data.
6 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-67
CO Line Ringing Pattern Selection for CO/PBX Line Mode
4-56
CO Line Ringing Pattern by Telephone or CO Selection
0 1 / 5 5 : C O R N G — | 1
T I M E D I S P L A Y
Data
No.
Tel Port
No.
(01~99)
A0~C0
Page
Setting
Data
Title
