NEC Xen Master - 7-1 Card Interface Slot Assignment

Card Interface Slot Assignment 1 - 403
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
7-1
System Mode
7
Submode
1
Data No.
—
PC Programming
a
+BS
Card Interface Slot Assignment
General Description
Use this Memory Block to specify the type of installed ETUs.
Display
Display
Programming Procedures
1 Go off-line.
2 Press LK7 + LK1
to access the Memory Block.
0 1 : D P I N T E R B
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
1 0 9 : =
1 0 1 :
Page
No.
Upper Slot No.
09~16 (A)
Unit Name
Port No.
Port No.
Unit Name
Lower
Slot No.
01~08 (B)
Cabinet
No.
1~3
