NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
3-22
System Mode
3
Submode
—
Data No.
22
PC Programming
a
+ALM
Tie Line Length of Delay Signal Selection
General Description
Use this Memory Block to specify the time a delay pulse is sent to another system.
Display
Settings
(Page 1)
LK 1
LK 2 LK 3 LK 4
The shaded area indicates the default setting.
0 ms. 300 ms. 600 ms. 900 ms.
LK 5 LK 6 LK 7 LK 8
1200 ms. 1500 ms. 1800 ms. 2100 ms.
(Page 2)
LK 1 LK 2 LK 3 LK 4
2400 ms. 2700 ms. 3000 ms. 3300 ms.
LK 5 LK 6 LK 7 LK 8
3600 ms. 3900 ms. 4200 ms. 4500 ms.
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + BB to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
S to go to the next page
T to go to the previous page
R to go to the next CO/PBX Line No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
N
1. Specify the Delay Method in Memory Block 3-14 Tie/DID Line Type Assignment.
0 1 / 2 2 : D E L Y 3 0 0 | 1
T I M E D I S P L A Y
CO/PBX
No.
(01~64)
Data
No.
Title
Page
No.
Setting
Data
Delay Pulse Sending
Receiving Side
Receiving Signal Detection
Time
DC Loop Supervision
To Next Page
