NEC Xen Master Programming Manual

ISDN DTMF Duration/Interdigit Time Selection 1 - 111
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
1-1-80
System Mode
1
Submode
1
Data No.
80
PC Programming
a
+AN
ISDN DTMF Duration/Interdigit
Time Selection
General Description
Use this Memory Block to specify tone duration and interdigit time of Dual-Tone
Multifrequency (DTMF) signals for the ISDN trunk.
Display
Settings
LK 1 LK 2LK 3LK 4
The shaded area indicates the default settings.
D.D I.T.
70ms 60ms
D.D I.T.
100ms 70ms
D.D I.T.
400m 100ms
D.D I.T.
600ms 100ms
LK 5 LK 6 LK 7 LK 8
D.D I.T.
900ms 200ms
Programming Procedures
1 Go off-line.
2 Press LK1 + LK1 +
HK to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
3-91
Trunk (Installed, DP/DTMF) Selection
8 0 : M F = 1 0 0 / 7 0
T I M E D I S P L A Y
Data
No.
Setting
Data
Title
