1 - 378 APR Hookflash Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
4-56
System Mode
4
Submode
—
Data No.
59
PC Programming
a
+BTM
APR Hookflash Selection
General Description
Use this Memory Block to allow/deny Hookflash for an Analogue Port Adapter (APR) on a
Multiline Terminal.
System Software S5500 or higher is required.
Display
Settings
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
NO YS
LK 5 LK 6 LK 7 LK 8
Programming Procedures
1 Go off-line.
2 Press LK4 +
EI to access the Memory Block.
3 Use the following to enter data:
J to move the cursor left
L to move the cursor right
K~I to enter numeric data or Tel Port No.
– OR –
R to go to next assigned Tel Port No.
Q+1 to enter A for Port Numbers 100~109
Q+2 to enter B for Port Numbers 110~119
Q+3 to enter C for Port Number 120
4 Press the corresponding CO/PBX line key to change the setting data option.
5 Press
Nto write the data and display Memory Block 4-1 for next Tel Port No.
6 Program the next Tel Port No. or press
PTo go back on-line.
Related Programming
M.B. Number Memory Block Name
1-1-02
Hookflash Time Selection
1-3-02
SLT Hookflash Signal Selection
4-40
APR Ring Mode Assignment
4-95
DTMF/DP SLT Type Selection
N
1. System Software version 5.0 or higher is required to support APR Hookflash.
2. Operation of SLT connected to APR is the same as the Single Line Telephone.
0 1 / 5 9 : H K F L S H N O
T I M E D I S P L A Y
Tel Port
No.
(01~CO)
Data
No.
Title
Setting
Data
To Next Page
