1 - 284 Tie Line Wink/Delay Signal Detect Timeout Selection
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
3-25
System Mode
3
Submode
—
Data No.
25
PC Programming
a
+ALM
Tie Line Wink/Delay Signal Detect
Timeout Selection
General Description
Use this Memory Block to specify a maximum time for receiving an acknowledgment signal
from a distant system before sending a busy tone.
Display
Settings
(Page 1)
LK 1 LK 2 LK 3 LK 4
The shaded area indicates the default setting.
No Limit 1 sec. 2 sec. 3 sec.
LK 5LK 6LK 7
LK 8
4 sec. 5 sec. 6 sec.
7 sec.
(Page 2)
LK 1 LK 2 LK 3 LK 4
8 sec. 9 sec. 10 sec. 11 sec.
LK 5 LK 6 LK 7 LK 8
12 sec. 13 sec. 14 sec. 15 sec.
Programming Procedures
1 Go off-line.
2 Press LK3 +
N + BE to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
Note: Use the following to enter data:
S to go to the next page
T to go to the previous page
R to go to the next CO/PBX Line No.
4 Press
Nto write the data.
5 PressPto go back on-line.
0 1 / 2 5 : D T E C T 7 s | 1
T I M E D I S P L A Y
CO/PBX
No.
(01~64)
Data
No.
Title
Page
No.
Setting
Data
Receiving Acknowledgment Signal
Originating Side
Sending an Outgoing Signal
Time
Timeout when the
acknowledgment
signal is not received.
To Next Page
