NEC Xen Master - 1-8-36 COM Port Parity;Stop Bit Setting Assignment

COM Port Parity/Stop Bit Setting Assignment 1 - 223
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
1-8-36
System Mode
1
Submode
8
Data No.
36
PC Programming
a
+CSS
COM Port Parity/Stop Bit Setting
Assignment
General Description
Use this Memory Block to define the Parity and Stop bit for the individual COM ports.
Display
Settings
LK 1LK 2LK 3LK 4
The shaded area indicates the default setting.
Non/1 Non/2 Even/1 Odd/1
LK 5LK 6LK 7LK 8
Programming Procedures
1 Go off-line.
2 Press LK1 + LK8 +
CF to access the Memory Block.
3 Use the Line keys to select the parity and stop bit setting. Default Values
COM 1 = Non/1
COM 2 = Non/1
COM 3 = Non/1 (Not Used)
COM 4 = Non/1
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
M.B. Number Memory Block Name
1-5-13
Printer Connected Selection
N
COM 1 = PC Programming/LCR
COM 2 = Station Message Detail Recording (SMDR)
COM 3 = Not Used
COM 4 = Automatic Call Distribution (Not used by Xen Axis system)
3 6 : P / S 1 = N O N / 1
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
