DISA/ID Code Assignment 1 - 229
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
1-9-00
System Mode
1
Submode
9
Data No.
00
PC Programming
a
+BD
DISA/ID Code Assignment
General Description
This Memory Block specifies the Direct Inward System Access (DISA) ID Code numbers.
Display
Programming Procedures
1 Go off-line.
2 Press LK1 + LK9 +
KK to access the Memory Block.
3 Use the dial pad to enter the data.
Setting Data:
2-digit DISA ID Code: 00~99 (00 no data)
3-digit DISA ID Code: 000~999 (000 no data)
4-digit DISA ID Code: 0000~9999 (0000 no data)
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
K~I to enter numeric data
R to access the next ID buffer number
Q+1, 2, 3 = A, B, or C for Port Number
ID Buffer Number:
01~99
A0~A9
B0~B9
C0
Default Values
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
No related programming is necessary for this Memory Block.
N
Assign 000 (No Data) for stations that are not installed or stations that are denied DISA access.
0 1 / 0 0 : C O D E = 1 0 0
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
ID Buffer No.
(01~C0)
If DISA ID Code is assigned as 2-digit:
ID Buffer Number 01~10 = DISA ID
Code 10~19
ID Buffer Number 11~20 = DISA ID
Code 20~29, etc.
If DISA ID Code is assigned as 3-digit:
ID Buffer Number 01~C0 = DISA ID
Code 100~219
If DISA ID Code is assigned as 4-digit:
ID Buffer Number 01~10 = DISA ID
Code 1000~1009
ID Buffer Number 11~20 = DISA ID
Code 1010~1019, etc.
