1 - 126 PHS Telephone Assignment
NEC Business Solutions Ltd Xen Master & Xen Axis
A6-324000-642-02 - Release 6.0
May 2003
1-2-21
System Mode
1
Submode
2
Data No.
21
PC Programming
a
+AP
PHS Telephone Assignment
General Description
Use this Memory Block to specify the number of PHS Telephones that can be used in the
system.
Display
Settings
(Page 1)
LK 1 LK 2 LK 3 LK 4
Port 01~04 Port 05~08
Port 0
9~12
Port 13~16
LK 5 LK 6 LK 7 LK 8
Port 17~20 Port 21~24 Port 25~28 Port 29~32
(Page 2)
LK 1 LK 2 LK 3 LK 4
Port 33~36 Port 37~40 Port 41~44 Port 45~48
LK 5 LK 6 LK 7 LK 8
Port 49~52 Port 53~56 Port 57~60 Port 61~64
(Page 3)
No PHS Telephones are assigned.
LK 1 LK 2 LK 3 LK 4
Port 65~68 Port 69~72 Port 73~76 Port 77~80
LK 5 LK 6 LK 7 LK 8
Port 81~84 Port 85~88 Port 89~92 Port 93~96
(Page 4)
LK 1 LK 2 LK 3 LK 4
Port 97~100 Port 101~104 Port 105~108 Port 109~112
LK 5 LK 6 LK 7 LK 8
Port 113~116 Port 117~120
Programming Procedures
1 Go off-line.
2 Press LK1 + LK2 + KDto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
LK is green = block assigned for PHS Telephones
LK is red = block not available for PHS (hardware is installed)
Default Values
No PHS Telephones are assigned.
Hardware equipped ports are red.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
0 4 : P H S A S S I G N 0 1
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
To Next Page
