NEC Xen Master - 5-02 8-Digit Matching Table to Trunk Group Assignment

8-Digit Matching Table to Trunk Group Assignment 1 - 393
Programming Manual May 2003
A6-324000-642-02 - Release 6.0 May 2003
5-02
System Mode
5
Submode
—
Data No.
02
PC Programming
a
+AC
The shaded area indicates the default setting.
8-Digit Matching Table to Trunk
Group Assignment
General Description
Use this Memory Block to assign each Trunk Group to the 8-Digit Matching Tables.
Display
Settings
(Page 1)
LK 1LK 2LK 3LK 4
There is no default setting.
Table 00 Table 01 Table 02 Table 03
LK 5 LK 6 LK 7 LK 8
Table 04 Table 05 Table 06 Table 07
(Page 2)
LK 1LK 2LK 3LK 4
Table 08 Table 09 Table 10 Table 11
LK 5 LK 6 LK 7 LK 8
Table 12 Table 13 Table 14 Table 15
Programming Procedures
1 Go off-line.
2 Press LK5 +
N+ KB to access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option. Operation data includes:
Note: Use the following to enter data:
J to move the cursor left
L to move the cursor right
S to go to the next page
T to go to the previous page
R to go to the next Trunk Group No.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
Related Programming
Refer to Section 6 Code Restriction in this chapter.
0 1 / 0 2 : 8 D G = T R K G | 1
T I M E D I S P L A Y
Title
Page
No.
Data
No.
Trunk Group
No. (01~32)
CO/PBX
Line LED
Off
On
Data Disabled
Enabled
