Call Arrival Key Block Assignment 1 - 119
Programming Manual May 2003
A6-324000-642-02 - Release 6.0
May 2003
1-2-04
System Mode
1
Submode
2
Data No.
04
PC Programming
a
+BK
Call Arrival Key Block Assignment
General Description
Use this Memory Block to specify the number of Call Arrival keys that can be used in the
system.
Display
Settings
(Page 1)
LK 1LK 2LK 3LK 4
Port 01~04 Port 05~08
Port 0
9~12
Port 13~16
LK 5 LK 6 LK 7 LK 8
Port 17~20 Port 21~24 Port 25~28 Port 29~32
(Page 2)
LK 1LK 2LK 3LK 4
Port 33~36 Port 37~40 Port 41~44 Port 45~48
LK 5 LK 6 LK 7 LK 8
Port 49~52 Port 53~56 Port 57~60 Port 61~64
(Page 3)
No Call Arrival Key Blocks are assigned.
LK 1LK 2LK 3LK 4
Port 65~68 Port 69~72 Port 73~76 Port 77~80
LK 5 LK 6 LK 7 LK 8
Port 81~84 Port 85~88 Port 89~92 Port 93~96
(Page 4)
LK 1LK 2LK 3LK 4
Port 97~100 Port 101~104 Port 105~108 Port 109~112
LK 5 LK 6 LK 7 LK 8
Port 113~116 Port 117~120
Programming Procedures
1 Go off-line.
2 Press LK1 + LK2 +
KDto access the Memory Block.
3 Press the corresponding CO/PBX line key to change the data option.
LK is green = block assigned for CAR
LK is red = block not available for CAR (hardware is installed)
Default Values
No Call Arrival Key Blocks are assigned.
Hardware equipped ports are red.
4 Press
Nto write the data.
5 Press
Pto go back on-line.
0 4 : C A R A S S I G N | 0 1
T I M E D I S P L A Y
Data
No.
Title
Setting
Data
